How to Install 2002 2004 Acura RSX Aftermarket Headlights

In the following article we will learn how to install aftermarket, replacement headlights on the 2002 through 2004 Acura RSX. The actual product shown is here http://www.rvinyl.com/Custom-Headlights-2LHP-RSX02G-TM.html but the procedure can be used with any aftermarket or OEM replacement headlamp.

Steps

  1. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 1
    1
    Open the hood of your vehicle.
  2. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 2
    2
    Locate and remove six plastic clips
  3. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 3
    3
    From underneath the bumper, remove eight more plastic clips
  4. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 4
    4
    Remove four screws from under the bumper as well
  5. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 5
    5
    Remove hidden screw that connects the bumper to the fender with screwdriver.
  6. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 6
    6
    Remove the bumper by gently rocking it from side to side.
  7. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 7
    7
    Remove plastic shield.
  8. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 8
    8
    Remove four screws from headlight.
  9. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 9
    9
    Unplug corner signal light.
  10. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 10
    10
    Remove screws and bracket from headlight. You will use the bracket to attach the replacement.
  11. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 11
    11
    Remove driving light and sockets.
  12. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 12
    12
    Install bracket and sockets on new light.
  13. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 13
    13
    Plug in all harnesses and connectors (including turn signal harness).
  14. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 14
    14
    Replace headlight screws.
  15. Image titled Install 2002 2004 Acura RSX Aftermarket Headlights Step 15
    15
    Follow steps 1 through 7 in reverse order.

Things You'll Need

  • Trim Pad Remover
  • Phillips Screwdriver
  • 1/4" Ratchet Driver
  • 10mm Socket
  • 1/4" Driver Extension
